CVT Electronic Header Green (yellow) Forage Harvester (9qsz-3000)
1. Features:Using the Germany champion's disc technique vertical cutting platform, working width 2.4metersThe engine by Yuchai engine, output power of 190 horsepower, reliable quality, fuel consumption is small;Free switching between 4WD walking and 2WD walking modes, improve the machine enviro......
Send Inquiry
Product Description
1. Features:
Using the Germany champion's disc technique vertical cutting platform, working width 2.4meters
The engine by Yuchai engine, output power of 190 horsepower, reliable quality, fuel consumption is small;
Free switching between 4WD walking and 2WD walking modes, improve the machine environment adaptability.
Adopt the operating system of electro-hydraulic control and CVT, electronic header, which is convenient for driver to operate;
Cast spout is in the way of rotating turbine, can be controlled wirelessly and remotely by handle;
Large capacity dump hopper, easy for the car-following operation;
Adjust the cutting length of the materials in multi-polar. The unique grain crushing and scrubbing device, straw rubbing rate is more than 95%, grain crushing rate is more than 90%.
2.Main Specifications:
Remark: Heavy chassis for standard
3. Quality certificate:
(1) CE Approved.
(2) Obtained the certificate of ISO9001:2008.
(3) Manufacturing license number:
4. Others:
(1) Packing: 1 unit naked within 1 x 40HQ container
(2) Delivery time: 40 days
(3) Accidental benefits: Customers can purchase wearing parts according to the parts list we offered.
(4) Guarantee Period: One year
(5) Offer Validity: 30 days
Using the Germany champion's disc technique vertical cutting platform, working width 2.4meters
The engine by Yuchai engine, output power of 190 horsepower, reliable quality, fuel consumption is small;
Free switching between 4WD walking and 2WD walking modes, improve the machine environment adaptability.
Adopt the operating system of electro-hydraulic control and CVT, electronic header, which is convenient for driver to operate;
Cast spout is in the way of rotating turbine, can be controlled wirelessly and remotely by handle;
Large capacity dump hopper, easy for the car-following operation;
Adjust the cutting length of the materials in multi-polar. The unique grain crushing and scrubbing device, straw rubbing rate is more than 95%, grain crushing rate is more than 90%.
2.Main Specifications:
| Items | Parameters |
| Operation way | Auto-run unlevel harvest |
| Cutting table type | vertical cylinder |
| Operation Range | 2400mm |
| Operation speed | 4-8km/h |
| Efficiency | 20-60T/h |
| Cutting Length | 7-50mm(adjustable) |
| Loss rate | ≤3% |
| Min cutting height | ≤150 |
| Engine Power | 140kw(190hp) |
| Dimension | 7100*2850*4730mm |
| Overall weight | 6900kg |
3. Quality certificate:
(1) CE Approved.
(2) Obtained the certificate of ISO9001:2008.
(3) Manufacturing license number:
4. Others:
(1) Packing: 1 unit naked within 1 x 40HQ container
(2) Delivery time: 40 days
(3) Accidental benefits: Customers can purchase wearing parts according to the parts list we offered.
(4) Guarantee Period: One year
(5) Offer Validity: 30 days
