Heavy Duty Horizontal CNC Lathe Machine for Machining Shaft (CG61160)
Large Heavy Duty CNC Horizontal Lathe MachineFor Machining Wheel Hub Turbine,Flange,Cylinder,Shaft,etc1.FANUC ,SIMENS or Chinese Brand system (Optional)2. Heavy Duty Horizontal lathe machine with 4 guide rails 3. Higher cutting rigidity. 4. One-piece base and higher rigidity5. Brand-new design6. Hig......
Send Inquiry
Product Description
Large Heavy Duty CNC Horizontal Lathe Machine
For Machining Wheel Hub Turbine,Flange,Cylinder,Shaft,etc
1.FANUC ,SIMENS or Chinese Brand system (Optional)
2. Heavy Duty Horizontal lathe machine with 4 guide rails
3. Higher cutting rigidity.
4. One-piece base and higher rigidity
5. Brand-new design
6. High configuration and low cost.
7. Maximize Customer's Profitability under the minimum invest cost.
After-sale Service :
1. Technicians of QINGDAO NORTH TORCH MACHINE CO.,LTD will provide necessary technically training for users' operators and maintenance staff to enable them to properly use and operate the lathe and carry out normal maintenance.
2. Warranty period: One year after acceptance of the lathe.
3. In case of any quality problem found in use, the factory will dispatch personnel away to the user's location within 48 hours (domestic users) & within 3 days (Foreign Customer) and the technical staff won't leave before resolving the malfuntion.
4. The company will provide different electrical and mechanical parts for the purchased lathe timely.
5. The company will provide lifetime guarantee for the consulting services in terms of application, maintenance, repair, renovation, etc of equipments.
For more details, please feel free to contact us. Thanks!
For Machining Wheel Hub Turbine,Flange,Cylinder,Shaft,etc
1.FANUC ,SIMENS or Chinese Brand system (Optional)
2. Heavy Duty Horizontal lathe machine with 4 guide rails
3. Higher cutting rigidity.
4. One-piece base and higher rigidity
5. Brand-new design
6. High configuration and low cost.
7. Maximize Customer's Profitability under the minimum invest cost.
| Name | CG61100 | CG61125 | CG61160 | CG61200 | CG61250 | CG61300 | |
| Description | Unit | ||||||
| Max. Swing Over Bed | mm | 1000 | 1250 | 1600 | 2000 | 2500 | 3000 |
| Max. Swing Over the skateboard | mm | 650 | 800 | 1200 | 1650 | 1800 | 2800 |
| Max. Weight of Work-piece | T | 10 | 15 | 20 | 20 | 20 | 40 |
| Max. Length of Work-piece | mm | 3000-12000 | |||||
| Gears of Spindle Speed | / | Infinitely Variable Speed/step-less speed | |||||
| Range of Spindle Speed | r/Min | 10-300 | 10-200 | 10-160 | 4-80 | 4-80 | 1.6-63 |
| Chuck Diameter | mm | 800 | 1000 | 1250 | 1600 | 2000 | 2500 |
| X,Z-Axis Feed Range | mm/Min | 0-3000 | |||||
| Horizontal Stroke | mm | 500 | 625 | 800 | 1000 | 1250 | 1000 |
| Longitudinal Stroke | mm | 3000-12000 | |||||
| Main Driving Motor | Kw | 11 | 22 | 45 | 75 | 75 | 75 |
| Cutting Force (Carriage) | Kn | 4 | 6 | 20 | 40 | 40 | 60 |
| Sleeve Diameter of Tailstock | mm | 180 | 180 | 290 | 290 | 290 | 480 |
| Spindle Diameter of tailstock | mm | 125 | 125 | 160 | 160 | 160 | 240 |
After-sale Service :
1. Technicians of QINGDAO NORTH TORCH MACHINE CO.,LTD will provide necessary technically training for users' operators and maintenance staff to enable them to properly use and operate the lathe and carry out normal maintenance.
2. Warranty period: One year after acceptance of the lathe.
3. In case of any quality problem found in use, the factory will dispatch personnel away to the user's location within 48 hours (domestic users) & within 3 days (Foreign Customer) and the technical staff won't leave before resolving the malfuntion.
4. The company will provide different electrical and mechanical parts for the purchased lathe timely.
5. The company will provide lifetime guarantee for the consulting services in terms of application, maintenance, repair, renovation, etc of equipments.
For more details, please feel free to contact us. Thanks!
