Drilling and Milling Machine (DM7025FG/DM7032FG/DM7040FG/DM7045FG)

Product Description

Drilling and Milling Machine

Items: DM7025FG DM7032FG DM7040FG DM7045FG

1. Max face mill capacity: 25/32/40/45mm

2. Max end mill capacity: 63/63/80/80mm

3. Spindle travel: 85mm and 130mm

Features:

1.Geer-driven and round column

2.Milling, drilling., tapping, boring and reaming

3.Head swivels ±90°Vertically

4.Micro feed precision

5.Adjustable gibs on table precision.

6.Strong rigiditypowerful cutting and precisely positioning

ITEM	DM7025FG	DM7032FG	DM7040FG	DM7045FG
Max Face mill capacity	25mm	32mm	40mm	45mm
Max End mill capacity	63mm	63mm	80mm	80mm
End milling capacity	20mm	20mm	32mm	32mm
Max.distance from spindle nose to table	445mm	450mm	450mm	450mm
Min.distance from spindle axis to column	203mm	260mm	260mm	260mm
Spindle travel	85mm	130mm	130mm	130mm
Spindle taper	M.T.3 or R8	M.T.3 or R8	M.T.4 or R8	M.T.4 or R8
Step of spindle speed	6	6	6	6
Range of spindle speed 50Hz	95-1420 r.p.m	80-1250 r.p.m	80-1250 r.p.m	80-1250 r.p.m
60Hz	115-1700 r.p.m	95-1500 r.p.m	95-1500 r.p.m	95-1500 r.p.m
Swivel angleof headstock(perpendicularly)	90°	90°	90°	90°
Table size	520×160mm	800×240mm	800×240mm	800×240mm
Forward and backward travel of table	140mm	175mm	175mm	175mm
Left and right travel of table	290mm	500mm	500mm	500mm
Motor Power	0.37KW	0.75KW(1HP)	1.1KW(1.5HP)	1.5KW(2HP)
Voltage/frequency	As customer's requirement	As customer's requirement	As customer's requirement	As customer's requirement
Net weight/gross weight	180kg/240kg	320kg/370kg	323kg/373kg	325kg/375kg
Packing size	680×750×1000mm	770×880×1160mm	770×880×1160mm	770×880×1160mm
Loading amount	48pcs/20 ' container	36pcs/20 ' container	36pcs/20 ' container	36pcs/20 ' container
